The Refrigerant gas containing oil in aerosol form exported from the compressor enters into the oil separator. The oil contained in the refrigerant gas is intercepted when it passes through the inlet metal web and the middle baffle and then the outlet metal web.
The oil particle collide with one another and form heavier oil particles than impinge on the surface of the oil separator's shell wall where there is a final separation. The separated oil drips to the bottom of the oil separator where a float operated needle valve return the oil back to the crankcase or oil resevoir.
- The Material of inlet and oulet is copper
- Max.Admissible Working Pressure [bar] : 31 10
- Admissible Working Temperature [°C] : 140..-10 -10..-40
- Applicative refrigerant : R134a,R22,R407c,R404a,R507a
